Product Featuresarrow_drop_down
- The automatic transfer switch is used for transferring electrical load from a UTILITY (NORMAL) power source to a GENERATOR (STANDBY) power source
- Suitable for use with a single-phase system, when the single-phase NEUTRAL line is to be connected to a neutral lug and is not to be switched
- Solderless, screw-type terminal lugs are standard
- A Smart A/C Module is standard in this switch
- Four LEDs located on the Smart A/C Module illuminate when a load is connected and powered
-
Specificationsarrow_drop_down
- Color: Gray
- Country of Origin: USA
- Depth: 7 in
- Enclosure Material: Aluminum
- Height: 20 in
- Installation: Standard
- Load Transition Type: Open
- Maximum Wattage: 24000
- Maximum Wire Size: 2/0-14 AWG
- Mfg Standards/Approvals: UL, Cul
- NEMA Enclosure Type: 3R
- Number of Phases: 1
- Sensing Line Failure: 0.6
- Suitable For Use With: QT02224ANAX, QT02515ANSX, QT02724ANAX, QT03015ANSX, QT03624ANAX, QT04524ANSC, QT04524ANSX, QT04854ANAC, QT04854ANAX, QT07068ANAC, QT07068ANAX, QT07068AVAC, QT07068AVAX, QT08046ANAX, QT08046AVAX, QT10068ANAC, QT10068AVAC, QT13068ANAC, QT13068AVAC, QT15068ANAC, QT15068AVAC, RD01523ADAE, RD02023ADAE, RD03024ADAE, RD04834ADAE, RG02224AGAX, RG02224ANAX, RG02515ANAX, RG02515ANSX, RG02724ANAX, RG03015ANAX, RG03015ANSX, RG03224ANAX, RG03624ANAX, RG03624ANSX, RG03824ANAX, RG04524ANAC, RG04524ANAX, RG04524ANSC, RG04524ANSX, RG04854ANAC, RG04854ANAX, RG04854AVAC, RG04854AVAX, RG06024ANAX, RG06024ANSX, RG06024AVAX, RG06024AVSX
- Voltage: 240
- Warranty: 2 yr
- Width: 14-5/8 in
-
