Product Featuresarrow_drop_down
- Omniguard total corrosion protection: Our enhanced evaporator coil helps protect against leaks and corrosion for long- term performance
- Microban protection : Drain pans are infused with an antibacterial agent that destabilizes the membrane of microorganism cells, disrupting the cellular function of odor-causing mold and bacteria
- Matched system: Our evaporator coils are specially designed and sized to match Armstrong Air heating and cooling products, removable cabinets and a single drain pan offer quick access and easy clean up
- MHT technology : Armstrong Air proprietary heat transfer system, the coil features rifled tubing to enhance refrigerant flow, while lanced coil fins increase surface contact between metal and air
- Fully insulated cabinet : Wall-to-wall insulation ensures less than 2% air leakage increasing efficiency and energy savings
- Dedicated horizontal
- Insulated galvanized steel case with durable embossed finish
- Removable panels provide access to coil
- Refrigerant lines extend outside of the cabinet for easy connection
-
Specificationsarrow_drop_down
- Air Flow Type: Horizontal
- Color: Platinum Gray
- Dimensions: 23-3/4 in L x 35 in W x 28-3/4 in H
- Flow Rate: 1400 to 2400 cfm
- Line Size (Liquid): 3/8 in
- Line Size (Suction): 7/8 in
- Metering Device: Piston Expansion
- Mfg Standards/Approvals: AHRI Certified | cULus Listed
- Nominal Capacity: 5 ton
- Refrigerant Type: R22/R-410A
- Series: EAH1P-50
- Tubing Material: Aluminum
- Type: Cased
- Warranty: 10 Years Limited Parts
-
